Standards

•Complies with IEEE 802.3, 10BASE-T, IEEE 802.3u, 100BASE-TX and 100BASE-FX Ethernet standards

Interface

•One 10/100BASE-TX port with RJ45 connector
•One 100BASE-FX port with ST/SC/WDM connector supporting multi-mode or single-mode fiber optic cable
•Auto-negotiation and auto-MDI / MDI-X for 10/100BASE-TX port

Layer 2 Features

•Back-pressure and IEEE 802.3x compliant flow control and full wire-speed forwarding rate
•Link Loss Return (LLR) switch on each fiber optic is to aid in troubleshooting remote network connections
•Link Loss Carry Forward (LLCF) works with LLR in diagnosing network connections

Smart Management

•Provides DIP switch for setting fiber ( HDX/FDX), UTP ( auto-negotiation / manual), speed (10/100Mbps), duplex mode (half/full), LLR ( disable/enable), LLCF ( disable/enable)
•Manageable through web smart/managed media converter chassis system (MC-1600MR/MC-1610MR series)

Hardware

•Used as a stand-alone device or works with web smart/managed media converter chassis for up to 16 converters with redundant power supply for optional expanding use
•LED indicators for converter status
•Choice of fiber-connector from ST/SC/WDM, multi-mode/single-mode fiber
•EMI standards complies with FCC, CE class B
