Physical Port
• 24-port 10/100/1000Base-T Gigabit RJ-45 copper
• 2 100/1000Base-X mini-GBIC/SFP slots
• RJ-45 console interface for switch basic management and setup
• Reset button for system factory default and reboot

Power over Ethernet
• Complies with IEEE 802.3at High Power over Ethernet
• Complies with IEEE 802.3af Power over Ethernet
• Up to 24 ports of IEEE 802.3af / 802.3at devices powered
• Supports PoE Power up to 30.8 watts for each PoE port
• 300-watt PoE budget
• Auto detects powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100m
• PoE Management

Layer 2 Features
• Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
• High performance Store and Forward architecture, runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
• Supports VLAN
• Supports Spanning Tree Protocol
• Supports Link Aggregation
• Provides port mirror (many-to-1)

Quality of Service
• Ingress / Egress Rate Limit per port bandwidth control
• Storm Control support
• Traffic classification
• Strict priority and Weighted Round Robin (WRR) CoS policies

Multicast
• Supports IGMP Snooping v2 and v3
• IGMP Querier mode support
• IGMP Snooping port filtering
• Up to 256 multicast groups
