Underwater Loose tube 12 Singlemode fibres
The cable type is intended for river and lakes or direct burial installation.

The cable contains 12 Singlemode color-coded optical fibercontained in 2 color-coded loose tubes. These tubes are filled with a thixotropic gel to prevent the ingress of water and SZ stranded around a dielectric central strength member. A specially formulated gel is applied between all the interstices in the cable core to block water passage. Fillers are used as needed to preserve cable geometry. Fiber-glass strength yarns reinforce the cable core beneath an inner jacket. A layer of galvanized steel wires is stranded around the inner jacket to serve as an armor. An outer jacket completes the cable structure.

This cable can be installed up to 100 meter depth.

Packaging: Drum 1000m, 2000 or request
Number of optical fibres: 12
Nominal outer diameter: 13,5 mm
Approximate weight: 290 kg/km

Applicable Standards
IEC 60794, IEC 60794-1-21/22, TIA/EIA-568

Installation
Guidelines as per IEC TR 6269
