Ideally, Surge Arrestors should be installed in a grounded wall entry plate. Another option is the fixation of the Surge Arrestor on a grounded bar or rail. ;If both possibilities are not feasible because of overruling conditions on site, the surge arrestor must be connected to the grounding system by individual grounding wires. ;The grounding wire kit includes the necessary cable and accessories to connect a Surge Arrestor with the grounding system, provided a ground bus terminal is not further than 0.5m away
FEATURES / BENEFITS
• Preassembled cable lug.
The cable lug to connect the grounding wire to the surge arrestor comes preassembled
to save installation time and ensure connection security.
• Screw Kit and field attachable lug included
To connect the grounding wire to the surge arrestor a hex head screw M8x12 with washer and lock washer is included.
For the optimal connection to the grounding point, which should be as short as possible,
a field attachable lug is included which is to be installed once the cable has been trimmed to the final length.
